◆Physical properties of Noah®5112:
Noah®5112 fluid， extinguishing agent for class a fire， is applied as a gas, but is liquid at room temperature. It is electrically non-conducting in both the liquid and gaseous state. The breakdown voltage of Noah®5112 fluid vapor under saturated conditions at 1 atm, 21⁰C over a 2.7 mm electrode gap is 15.6kV, nearly 2.3 times that of dry nitrogen. The breakdown voltage of liquid Noah®5112 fluid under the same conditions is 48 kV.
The properties of Noah®5112 extinguishing agent for class a fire are similar to many of the first-generation halon alternatives with one primary exception – this compound is a liquid at ambient conditions. The boiling point of Noah®5112 fluid is 49.2⁰C, meaning this product has a much lower vapor pressure than other clean agents, which are gases at ambient conditions. Noah®5112 fluid has a very low heat of vaporization, approximately 25 times less than that of water. This, along with a vapor pressure 12 times higher than water causes Noah®5112 fluid to evaporate more than 50 times faster than water. This allows the agent to transition from a liquid to a gaseous state very rapidly. When discharged through a nozzle from a properly designed system, Noah®5112 fluid will rapidly vaporize and evenly distribute throughout the protected space.
◆Quality index:
Inspected Item | Qualified Product | Superior Product |
Purity, %, | ≥99.70 | ≥99.90 |
Acidity, (as HCI), % | ≤3x10-4 | ≤3x10-4 |
Water content, % | ≤10x10-4 | ≤5x10-4 |
Non-volatile residue, % | ≤0.01 | |
Quality standard: | Q/NY002-2018 |
◆Certificate:
◆UL listed
◆REACH registration; K-REACH (for South Korea)
◆FM Approved
◆Concentrations & safety margins comparison:
Noah®5112 | Halon1301 | HFC-227ea | CO2 | |
Use concentrations % | 4.5-5.9 | 5 | 7.5-8.9 | >30 |
NOAEL % | 10 | 5 | 9 | <5 |
Safety Margins % | 72-122 | 0 | 5.9-20 | Lethal |
◆Environmental parameters comparison:
Noah®5112 | Halon1301 | HFC-227ea | HFC-236fa | |
ODP | 0 | 12 | 0 | 0 |
GWP | 1 | 6900 | 3800 | 9400 |
ALT(year) | 0.014 | 65 | 36.5 | 226 |
◆Main application:
1. Noah®5112 is a green environmental, efficient and clean fire extinguishing agent, can be widely used all over the regional or local regional fire extinguishing system and portable fire extinguisher, especially applicable to electronic control center, computer room, transformer room, power distribution cabinets, wind power equipment room, energy storage power station, high precision instrument, museum, data processing center, ship control rooms, new energy vehicle lithium battery protection and other occasions of fire protection.
2. It can be used as coolant for electronic equipment and protection gas for light metal smelting. It can also be used to replace sulfur hexafluoride for transformer protection.
