◆Introduction:
FK-5-1-12 suppression agent is the most eco-friendly chemical clean agent available.
Inert gas is the most environmentally friendly, with zero ozone depletion potential (OPD) and zero GWP
Clean agent fire suppression systems can protect valuable assets and equipment when traditional fire sprinkler systems using water or foam can cause as much (or more) damage as a fire. Some typical applications and areas protected by detergent systems include:
CNC and EDM machines
Electrical Cabinets and Panels
Components inside a wind turbine nacelle
Data storage and telecommunications systems
Records/File Repositories and Libraries
Museums, artworks and other culturally significant assets
◆Physical properties of Noah®5112:
Molecular mass | 316.045 |
Boiling point at 1atm | 49.2℃ |
Freezing point | -108℃ |
Critical temperature | 168.7℃ |
Critical pressure | 18.65 Bar |
Critical density | 639.1 kg/m3 |
Heat of vaporization at boiling point | 88.0 kJ/kg |
Liquid Viscosity @25℃ | 0.524 cp |
Solubility of water in Noah5112 @25℃ | <0.001 wt% |
Specific heat，liquid@25℃ | 1.013 kJ/kg ℃ |
Specific heat capacity at room temperature@25℃,1atm | 0.0733m3/kg (1.175ft3/lb). |
Saturated liquid density（25℃） | 1.60 g/ml |
Vapor pressure（25℃） | 0.404 bar |
Insulating property (110k) | 3.8mA (Standard leakage current≤10mA) |
Dielectric strength (kV) | 74.6 kV (Test distance 3mm) |
ODP | 0 |
GWP | 1.0 |
ALT(year) | 0.014 |
◆Quality index:
Inspected Item | Qualified Product | Superior Product |
Purity, %, | ≥99.70 | ≥99.90 |
Acidity, (as HCI), % | ≤3x10-4 | ≤3x10-4 |
Water content, % | ≤10x10-4 | ≤5x10-4 |
Non-volatile residue, % | ≤0.01 | |
Quality standard: | Q/NY002-2018 |
◆Certificate:
◆Concentrations & safety margins comparison:
◆Environmental parameters comparison:
Noah®5112 | Halon1301 | HFC-227ea | HFC-236fa | |
ODP | 0 | 12 | 0 | 0 |
GWP | 1 | 6900 | 3800 | 9400 |
ALT(year) | 0.014 | 65 | 36.5 | 226 |
