Introduction:
hfc-227ea agent is accepted and respected worldwide, including a long history of protecting some of the world’s most critical and irreplaceable assets. Clean agent system, which includes the use of hfc-227ea agent, extinguishes a fire quickly by discharging in 10 seconds or less, stopping ordinary combustible, electrical, and flammable liquid fires before they can cause significant damage. When fire is extinguished this quickly, in addition to less fire damage, you’ll likely have no downtime and/ or disruption of business.
Safe for use where people are present, hfc-227ea agent system removes heat and breaks up the fire at the molecular level. And because it discharges as a gas, it leaves no residue and doesn’t require costly clean-up like water or dry chemical systems. Perhaps the most well respected and globally recognized of all clean agent fire suppressants, hfc-227ea agent applications range from computer and electronic rooms to museums and military vehicles.
Physical properties:
Property | |
Chemical Name | 1,1,1,2,3,3,3-Heptafluoropropane |
Chemical Formula | CF3CHFCF3 |
Molecular Weight | 170.03 |
Boiling Point, 1 atm, °C (°F) | –16.34 (2.59) |
Freezing Point, °C (°F) | –131 (–204) |
Critical Temperature, °C (°F) | 101.75 (215.1) |
Critical Pressure, kPa (psia) | 2925.0 (424.24) |
Critical Density, kg/m3 (lb/ft3) | 594.25 (37.098) |
Liquid Density at 25 °C (77 °F), kg/m3 (lb/ft3) | 1387.7 (86.63) |
Density, Saturated Vapor at Boiling Point, kg/m3 (lb/ft3) | 8.4860 (0.52979) |
Vapor Density at 25 °C (77 °F) and 1 atm | 7.1461 (0.4461) |
Specific Heat, Liquid (cP) at 25 °C (77 °F), kJ/kg-°C (Btu/lb°F) | 1.1816 (0.28242) |
Specific Heat, Vapor (cP) at 25 °C (77 °F), kJ/kg-°C (Btu/lb°F) and 1 atm | 0.81327 (0.81327) |
Vapor Pressure, Saturated at 25 °C (77 °F), kPa (psia) | 454.73 (65.9) |
Heat of Vaporization at BP, kJ/kg (Btu/lb) | 131.77 (56.7) |
Thermal Conductivity, Liquid at 25 °C (77 °F), W/m–°C (Btu/hr-ft°F) | 0.060491 (0.034975) |
Thermal Conductivity, Vapor at 1 atm, W/m-°C (Btu/hr-ft°F) | 0.013336 (0.0077103) |
Viscosity, Liquid at 25 °C (77 °F), cP (lb/ft-hr) | 0.23935 (0.57901) |
Viscosity, Vapor at 1 atm, cP (lb/ft-hr) | 0.011590 (0.028038) |
Relative Dielectric Strength at 1 atm, 25 °C (77 °F) (N2=1) | 2.00 |
Solubility of Water in FM-200™ at 20 °C (68 °F), ppm | 600 |
Ozone Depletion Potential, ODP | 0.0 (CFC-11 = 1) |
Global Warming Potential, GWP (100 yr ITH. For CO2, GWP = 1) | 3220 |
Atmospheric Lifetime, yr | 34.2 |
TSCA Inventory Status | Reported/Included |
European List of New Chemical Substances | EINECS, Listed (207-079-2) |
Certificate:
UL listed and REACH registered
Applications:
hfc-227ea agent is safe for use in applications where people are normally present (normally occupied spaces) for both Class-A and Class-B fire assets. hfc-227ea agent is intended to prevent or extinguish fires in situations where conventional extinguishing agents such as water, dry chemical, and carbon dioxide are unacceptable because they may cause collateral damage, significantly interrupt business productivity, or present a safety risk. These situations exist primarily where there is electrical or sensitive electronic equipment servicing a critical operation, the loss of which would not only be the value of the equipment but also the cost of business interruption. Other situations involve delicate or irreplaceable materials such as those found in museums, libraries and historical sites.
Applications where hfc-227ea agent is an excellent choice for a total flood fire suppression system also include computer rooms, telecommunication switch stations and facilities, semiconductor manufacturing facilities, data processing centers, clean rooms, and industrial process control rooms. Other examples of applications, include pleasure craft engines compartments, petrochemical facilities, chemical storage rooms, paint lockers, and other applications with hydrocarbon-based materials.
